Red Lion RJC-100 115/230 Volt, 1 HP 20 GPM Premium Convertible (Shallow or Deep Well) Jet Pump, Red, 602038

Product Description Red Lions 1 HP RJC-100 convertible jet pump is ideal for the supply of fresh water to cottages, cabins, and small homes that have wells down to 90 feet. Convertible jet pumps can be used in shallow wells down to 25-feet (injector is installed directly on the pump), or in deep well applications down to 90 feet (injector is installed in the well). If using the pump in a deep well application, replace the injector in the well as the injector is designed specifically for this pump and will give you optimal performance. This pump includes a 30/50 pressure switch and injector kit. This is a dual voltage pump and is factory set to 230 Volts. If wiring to 115 Volt power source, voltage switch must be changed to 115 Volts otherwise pump will not perform as expected. See owner's manual for instructions. This pump is rated for 20 GPM. From the Manufacturer This jet pump is Ideal for use in pumping at depths of 25-Feet or less for shallow wells and up to 90-Feet deep wells and is corrosion and rust resistant. Extremely versatile, produces up to 50 PSI with automatic shut-off. Features voltage selector for simple connection to existing power sources.

• APPLICATION: Convertible jet pump with deep well injector is ideal for use in shallow wells (less than 25 ft.) and deep wells (25 to 90 ft)
• BUILT TO LAST: rugged cast iron casing; glass-filled thermoplastic impeller and diffuser, thermally protected motor
• HEAVY-DUTY MOTOR: dual-voltage (115/230 V) motor features copper windings to ensure high efficiency and dependable motor life; 16.4 Amps at 115 Volts; 8.2 Amps at 230 Volts
• Comes factory pre-set for 230 Volts; easily switchable to 115 Volts; voltage must be selected to match incoming power source (see owner's manual)
• PUMP SPECIFICATIONS: 20 GPM at 5-ft. lift (30 PSI); 1-1/4 inch FNPT intake; 1-inch discharge; 30/50 pressure switch and injector kit included
