Hydraulic Power Unit 8 Quart Double Acting Hydraulic Pump Dump Trailer 12V DC Steel Hydraulic Pump for Dump Trailer Car Lifting 3KW Hydraulic Electric Pump Horizontal

Hydraulic Power Unit 8 Quart Double Acting Hydraulic Pump Dump Trailer 12V DC Steel Hydraulic Pump for Dump Trailer Car Lifting 3KW Hydraulic Electric Pump HorizontalPackage Included1* Hydraulic Electric Pump1* Connector1* 4.5-meter Wired Control Handle1* English User ManualSpecificationsMaterial: SteelColor: Black, SilverType: HorizontalRated Speed: 2850R/MINInternal Thread Model: m14 * 1.5Connector Model Configured: 18 * 1.5Connector Model Additionally Configured in the Package: 9/16''(SAE6)Power: 3KWVoltage: DC12VTank Capacity: 7.57L/ 8QtCord Length: 4.5m/14.76ftRelease Pressure: 16MPaRecommended Hydraulic Oiil: ISO VG22-46 (0 ℃ - 70 ℃): ISO VG15 (- 15 ℃ - 0 ℃)Tolerance Range of Power Supply Voltage: ± 10%Packing Size: 65*28*28cm/25.59*11.02*11.02inProduct Size: 17.78*17.78*50cm/7*7*19.7inGross Weight: 15kgkg/33.33lbsNotes1.The hydraulic oiil should be replaced upon working for 100 hours since the initial filling.Subsequently, the hydraulic oiil should be replaced once per year/ about 1500 working hours.2.The power unit could not filter foreign materials within the hydraulic cylinder, therefore, the interior of the hydraulic cylinder must be kept clean to prevent the ill-function of the control valve.And the pipelines should also keep clean.3.The oiil filling volume of the oiil tank shall be 90% of the capacity, and the oiil volume shall not be less than 85%.4.Please note that the cleanliness level of hydraulic oiil is ISO 4006 (: 99) 18/15 or NAS1638 9~10, and the product oiil must pass 10-25 μm The oiil filter truck can be used as working oiil after filtering.

• 💪【Solid and Durable】 The housing is made of high-quality steel, which is solid, wear-resistant, ru-stproof, and impact-resistant, ensuring a long service life.Hydraulic Pump is compact and lightweight(31.96lbs), allowing it to be easily installed on electric basketball stands, snow sweepers, truck tailgates, etc. without being abrupt, and also making it easy to carry and move.
• 💪【High Performance & Low Noise】 It is a double-acting pump, which can be used to lift and lower the hydraulic system to effectively handle a lot of work.The volume is low when it operates, giving you a quiet and comfortable working environment.
• 💪【Stable and Efficient】 The hydraulic electric pump is equipped with a powerful 12V DC motor for stable performance and quick start-up. So, It can provide strong power for hydraulic systems such as car elevators and lifters to achieve short-term lifting, greatly improving working efficiency.
• 💪【Safety Protection】 Double Acting Hydraulic Pump Dump is equipped with an overflow valve, so it will automatically release when overpressure to avoid overpressure damage or excessive pressure, making it safe and reliable to use.
• 💪【Easy to Use】 This hydraulic electric pump can be used directly after receiving without additional assembly requirements. At the same time, the English operating instructions are also provided in the package to facilitate your operation and installation.
